Description:
Flexibility
An open system for integrated CAD/CAM workflow allows for the export of STL files for easy file transfer and thus optimized collaboration
Impressive Speed
Intelligent scan-detecting algorithm with two high-speed cameras for quick and efficient intraoral scanning
Powderless
No need for powder in most regular cases, allowing for a seamless scanning process and increased patient comfort
| High Accuracy | |||
| In vitro* | In vivo** | ||
| Trueness | Precision | ||
| Single | 5.3μm ± 0.34 | 3.2μm ± 0.49 | 10μm |
| Quadrant | 17.3μm ± 0.43 | 6.3μm ± 0.63 | 25μm |
| Full arch | 21.0μm ± 1.48 | 22.6μm ± 7.55 |
50μm |
Small tip
Simpler maneuverability and improved patient comfort while scanning are the advantages of i500’s small tip
Single button control
No need to reach for the computer as the user can start, stop, and move to the next scanning stage by pressing a single button on the device
High resolution
Easy to locate margin lines and undercuts as well as distinction between tooth structure and soft tissue thanks to realistic high-resolution images
3D full color streaming capture for precise scans and detail-rich images
Video type
3D-in-motion video technology that allows for rapid video-based scans without worrying about choppy results
Lightweight
Our i500 intraoral scanner only weighs 280 grams and is exceptionally easy to hold, making the scanning process comfortable
Specification:
| Category | Description |
| Tip Size | 19 x 15.2 mm (WxH) |
| Overall Handpiece Length | 266 mm |
| Weight | 280g (0.8 LB ) |
| Imaging technology | 3S-in-motion video technology |
| Color | 3D full color streaming capture |
| Connectivity | USB 3.0 |
| Scanning Area | 14 x 13 mm |
